Quark-Elec NMEA 0183 to NMEA 2000 Mini Gateway QK-AS01

Sophisticated NMEA 0183 to NMEA 2000 mini gateway.

• Designed to easily fit onto most surfaces
• Small enough to fit behind instrument panels
• Compatible with most NMEA 0183 devices
• Supports the conversion of the majority of NMEA 0183 sentences

Description

Introduction

The QK-AS01 provides an easy mini gateway to linking older NMEA 0183 devices to the newer NMEA 2000 network by converting NMEA 0183 output sentences to NMEA 2000 PGNs. The QK-AS01 is compatible with most NMEA 0183 devices and supports the majority of NMEA 0183 sentences.

Features

• Galvanic opto-isolation on NMEA 2000 CAN bus connection
• Automatically detects and adjusts the NMEA 0183 input baud rate
• Comes with a pre-fitted 1-meter NMEA 2000 cable
• Small in size so can be easily installed behind instrument panels for minimal disruption to space
• Fitted with a 5-core screened cable for the NMEA 2000 connection

What’s included

1 x NMEA 0183 to NMEA 2000 mini gateway
